• Neck Type: Wizard C 3pc Roasted Maple/Bubinga
• Body: Nyatoh
• Fretboard: Roasted Birdseye Maple w/ Mother of Pearl Step Off-Set Dot Inlays
• Frets: 24 Jumbo Stainless Steel
• Bridge: Ibanez Mono-Tune
• String Spacing: 10.8mm
• Neck Pickup: R1 (S) Passive/Ceramic
• Middle Pickup: R1 (S) Passive/Ceramic
• Bridge Pickup: Q58 (H) Passive/Ceramic
• Factory Tuning: E Standard
• Strings: D'Addario EXL110 (.010–.046)
• Hardware Color: Cosmo Black

Neck Dimensions

• Scale: 648mm / 25.5"
• Width @ Nut: 42mm
• Width @ 24F: 57mm
• Thickness @ 1F: 21mm
• Thickness @ 12F: 22mm
• Fingerboard Radius: 305mmR

The Q54W features the dyna-MIX9 system with an Alter Switch, enabling nine tonal variations.

Alter Switch Off:

• Neck position: Neck pickup
• Between neck & center: Neck + center
• Center: Center pickup
• Between center & bridge: Center + neck side of bridge pickup
• Bridge: Bridge pickup

Alter Switch On (Two-Hum Tap Mode):

• Neck: Neck + center in series
• Neck/Center position: Neck + bridge side of bridge pickup
• Center: Neck + center in series + bridge
• Center/Bridge position: Neck side of bridge pickup
• Bridge: Bridge pickup

With the guitar in playing position:

• Five-way pickup selector: Closest to knee cut
• Tone knob: Closest to end of body
• Volume knob: Above pickup selector
• Alter Switch: Between volume and tone knobs

• Gig Bag Included
• Recommended Case: MR350C
• dyna-MIX9 Switching System
• Ibanez Custom String Lock
• Luminescent Side Dots

• Wizard C 3pc Neck: Neutral, versatile shape with great stability.
• Nyatoh Body: Rich mid-low presence.
• R1 / Q58 S-S-H Pickup Set: Designed for headless clarity, balance, and low noise.
• Custom String Lock: One-piece durable system supporting any string brand/gauge.
• Mono-Tune Bridge: Wide intonation range and easy action adjustments.
• dyna-MIX9 System: 9 tonal options with humbucker simulation modes.
• Roasted Birdseye Maple Fretboard: Exotic look with rich sustain.
• Jumbo Stainless Frets: High durability and effortless articulation.
• Ergonomic Body Design: Curves optimized for comfort.
• Compact & Lightweight: Solid, resonant non-chambered body.
• Luminescent Side Dots: High visibility on dark stages.
