• Neck Type: GRG Maple Neck
• Body: Poplar
• Fretboard: Bound Purpleheart, Reversed Black Sharktooth Inlays
• Frets: 24 Medium
• Bridge: Double Locking Tremolo
• String Spacing: 10.5mm
• Neck Pickup: Infinity R (H) Passive/Ceramic
• Bridge Pickup: Infinity R (H) Passive/Ceramic
• Factory Tuning: 1E,2B,3G,4D,5A,6E
• String Gauge: .009/.011/.016/.024/.032/.042
• Nut: Locking Nut
• Hardware Color: Black

• Scale Length: 648mm / 25.5"
• Width at Nut: 43mm
• Width at 24F: 58mm
• Thickness at 1F: 19.5mm
• Thickness at 12F: 21.5mm
• Fingerboard Radius: 400mmR

Description: a: Width at the nut b: Width at the specified fret c: Thickness at 1st fret d: Thickness at specified fret Radius: Fingerboard curvature

When the pickup selector switch is:

• Neck Position: Neck pickup selected
• Between Neck & Center: Bridge side of neck pickup
• Center Position: Both pickups active
• Between Center & Bridge: Bridge side of neck + bridge side of bridge pickup
• Bridge Position: Bridge pickup active

With the guitar in playing position:

• Closest to the neck: 5-way pickup selector switch
• Closer to the input jack: Tone knob
• Above the selector switch: Volume knob

• Recommended Case: M300C
• Maple Neck: Bright, stable neck construction
• Purpleheart Fretboard: Enhances tonal richness and visual appeal
• Double Locking Tremolo: Keeps tuning stable even under aggressive use
• Mono-Unit Output Jack: Durable, single-piece jack design for reliability
• Infinity R Pickups: Tight, clear, and dynamic tone with excellent clarity under gain
